The TV Shield PRO Kiosk Indoor and Outdoor TV Enclosure with Stand: Experience Affordability and Durability
| Overview |
| Specifications |
| Protects Against |
| Protection Notes |
| With Our Solution: Any TV Can be a Tough Indoor or Outdoor Kiosk!  | ||
|
| ||
Kiosk Overview
Call for Availability and Bulk Pricing for 5 or More Units
This Weatherproof TV Kisok (a Robust TV and Display Enclosure Paired with a Pedestal Stand) Protects a 27-32" TV or Digital Display (Flatscreen Including LCD, LED, OLED, and More)
The TV Shield PRO ™ Outdoor Digital Signage Kiosk is a weatherproof, secure, and robust pedestal mounted enclosure made with outdoor powder-coated steel for ultimate strength and durability. Designed for use with any standard indoor or outdoor TV or digital display, it is ideal for many commercial markets. Developed for outdoor areas, The TV Shield PRO Outdoor Digital Signage Kiosk‘s two-part easy install system is faster to install and maintain than other kiosk solutions and effortlessly opens for easy access to the display and inputs. The enclosure is secured using tamper resistant security screws while the pedestal is secured using high strength chambered key locks. Unit also features a dual thermostatically controlled fan system with 45ppi filtration. This professional-grade TV and display enclosure with stand includes laminated safety glass for strong defense against impact while offering patron protection.
Features:
- Fully weatherproof with multi-point sealing system to protect not only the internal display but also additional equipment within pedestal
- 2 year warranty for guaranteed peace of mind
- Housing secured with multiple high strength security screws to prevent unwanted tampering and theft of the display
- Protection equal to IP-55 standards (IP-65 equivalency for the available touch frame)
- Ample interior space withing the pedestal to house power supplies, data and networking equipment, mini-PC’s, digital signage drivers etc.
- 42” x 8” removable access panel on pedestal with high-strength chambered key lock preventing tampering or theft and allowing easy access to internal equipment
- Dual thermostatically controlled fan system with 45ppi filtration
- Laminated safety glass for strong defense against screen impacts and patron protection
- Heat dissipation venting on both the enclosure and pedestal
- Easily removable front panel offering quick access to the display for maintenance
- Easy access and removal of internal mount with draw string locking mechanism (100x100 to 400x400 VESA)
- Two-part assembly for ease of installation on site and reduced shipping costs
- 3” x 4” bottom power/cable entry system allows for direct placement over stub-out
Specifications |
| Material: | Outdoor powder-coated steel housing and stand with a laminated safety glass front panel for strong defense against screen impacts |
| Surface Finish: | Fine Texture Matte Finish |
| Color: | Fine Texture Black (additional colors are available for bulk orders of 10 units or more) |
| Dimensions: | Maximum TV Dimensions: Width (18.5") Height (30.64") Depth (3.6") Maximum INSIDE Dimensions: Width (20.2") Height (32.2") Depth (4.75") OUTSIDE Dimensions W/pedestal: Width (20.5") Height (69.75") Depth (10.05") |
| Fit Screen Size: | 27"-32" |
| Internal Mounting Hole Pattern : | VESA Only |
| Internal Mount VESA Compatible: | 75x75, 100x100, 200x200, 300x200, 300x300,400x300,400x400 |
| Max. Mounting Hole: | 400x400 |
| Weight Capacity: | 100 lbs. |
| Strength Tested: | 3 Times Approved |
| Mount Extension: | 1.1" |
| Screen Level: | +3°~-3° |
| Mount Type: | Flat Fixed |
| Direction Indicator: | Yes |
| Cable Management: | Yes |
| Anti-theft: | Yes |
| Accessory Kit Package: | Normal/Ziplock Polybag,Compartment Polybag |
Protects Against
This Weatherproof TV Kiosk Enclosure Protects Displays and TVs from Everything in Nearly Any Environment:
-
Water (Rain, pool splashes, sprinklers)
-
Moisture (Condensation, dew, steam, humidity, dampness)
-
Dust (Grime build-up)
-
Tampering (Burglary, theft, vandalism, attempted destruction of product)
-
High impact (Storms, branches, baseballs, flying objects)
-
Extreme temperatures (Hot and cold)
-
Sun
Protects Notes
Other Things You Should Know:
-
This protective TV case is not designed to be water-submerged
-
Thermostatic heaters are available upon request (turns on at 41° F and turns off at 47°)
* Protective Enclosures Company, LLC will not be held responsible for orders placed for TVs or displays over the listed specifications, and although we will accept a return, there will be a 10% restocking fee assessed, as well as the customer will be responsible for actual shipping and return shipping of the unit. If you plan to use an enclosure outside of the recommended and listed specifications, please make sure it will work for you before you order. By purchasing, you acknowledge that you have read and accept these terms and will hold harmless, PEC and all subsidiaries, business partners, and officers.
